Condair Sigma - Unit Configuration

52 Mounting and installation work
5.6.5 Unitconguration
All setting components for the unit congration are located on the control board:
– Rotary switch "Cylinder": cylinder type
– Potentiometer "Drain Factor": drain factor
– Potentiometer "Power Limit": power limitation
– DIP switch "Settings": general settings
Setting the steam cylinder type ("Cylinder")
Use the rotary switch "Cylinder" to select the type of steam cylinder used:
Voltage/
Phase
200/1
230/1
400/2
200/3
230/3
400/3
200/3
230/3
400/3
200/3
230/3
400/3
200/3
230/3
400/3 400/3 400/3
Position 0 1 2 3 4 5 6 7 8 9 A B
Cylinder ype
RD 422
522A
822A
524A
824A
532A
832A
534A
534A-L
834A
834A-L
1532A 1534A
1534A-L
2362A 2364A
2364A-L
3262A 3264A
3264A-L
4564A
4564A-L
6564A
Setting the drain factor
Use the potentiometer "Drain Factor" to set the drain factor (setting range: 0.5...2.0, factory setting: 1.0).
Setting the power limitation
Use the potentiometer "Power Limit" to set the power limitation in % of the maximum capacity (setting
range: 30...100%, factory setting: 100%).
General settings ("Settings")
With the DIP switches "Settings" you can set different unit parameters. The unit parameters are preset
in the factory and may only be modied by the client after consulting the Condair representative.
Switch Factory setting Description
1 OFF ON: low water conductivity <125 µS/cm
OFF: normal water conductivity ≥125 µS/cm
2 OFF ON: standby draining (72 hours) activated
OFF: standby draining (72 hours) deactivated
3 OFF ON: forced draining (72 hours) activated
OFF: forced draining (72 hours) deactivated
4 OFF ON: steam cylinder replacement interval 2500 h.
OFF: steam cylinder replacement interval 1500 h.
5 ON ON: the heating voltage is interrupted during draining of the steam cylinder
OFF: the heating voltage is interrupted during draining and relling of the steam cylinder
6 OFF ON: Offset control signal activated (2-10V)
OFF: Offset control signal deactivated (0-10V)
