2.6 MP-Keypad
MP-Keypad gives the user access to two menus. Menu 40 is for MP-Keypad setup and Menu 41 selects commonly used parameters for quick
browsing.
Table 2-1 Menu 40 parameter descriptions
Table 2-2 Menu 41 parameter descriptions
For more information about the MP-Keypad, see the SM-Keypad Plus User Guide.
Parameter
Range(
Ú) Default(Ö)
Type
40.00 Parameter 0 0 to 32767 0 RW Uni
40.01 Language selection
English (0), Custom (1), French (2),
German (3), Spanish (4), Italian (5)
English (0) RW Txt US
40.02 Software version
99999 RO Uni PT
40.03 Save to flash
Idle (0), Save (1), Restore (2),
Default (3)
Idle (0) RW Txt
40.04 LCD contrast
0 to 31 16 RW Uni US
40.05
Drive and attribute database upload was
bypassed
Updated (0), Bypass (1) RO Txt PT
40.06 Browsing favourites control
Normal (0), Filter (1) Normal (0) RW Txt
40.07 Keypad security code 0 to 999 0RWUni US
40.08 Communication channel selection
Disable (0), Slot1 (1), Slot2 (2),
Slot3 (3), Slave (4), Direct (5)
Disable (0) RW Txt US
40.09 Hardware key code
0 to 999 0RWUni US
40.10 Drive node ID (Address) 0 to 255 1RWUni US
40.11 Flash ROM memory size 4Mbit (0), 8Mbit (1) RO Txt PT US
40.19 String database version number 0 to 999999 RO Uni PT
40.20 Screen saver strings and enable
None (0), Default (1), User (2) Default (1) RW Txt US
40.21 Screen saver interval
0 to 600 s 120 RW Uni US
40.22 Turbo browse time interval 0 to 200 ms 50 ms RW Uni US
40.23 Product identification
Unidrive SP (0),
Commander SK (1), Mentor MP (2),
Affinity (4), Digitax ST (5)
RO Txt
Parameter
Range(
Ú) Default(Ö)
Type
41.00 Parameter 0 0 to 32767 0 RW Uni
41.01
to
41.50
Browsing filter source F01 to F50 Pr 0.00 to Pr 22.99 0RWUni
41.51 Browsing favourites control Normal (0), Filter (1) Normal (0) RW Txt
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar
Bit Bit parameter Txt Text string FI Filtered DE Destination
NC Not copied RA Rating dependent PT Protected US User save
PS Power down save
