Parameter structure Keypad and display Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Mentor MP Advanced User Guide 13
Issue Number: 4 www.controltechniques.com
2.7 Parameter access level and security
The parameter access levels determine whether the user has access to
Menu 0 (in sub block mode) only or to all of the advanced menus (Menus
1 to 23), in addition to Menu 0 (in linear mode).
The user security determines whether the access to the user is read only
or read write.
The user security and the parameter access level can operate
independently of each other as shown in Table 2-3 .
Table 2-3 User security and parameter access levels
RW = Read / write access RO = Read only access
The default settings of the drive are parameter access level L1 and User
Security Open, i.e. read / write access to Menu 0 with the advanced
menus, not visible
2.7.1 User security
The user security, when set, prevents write access to any of the
parameters (other than Pr 11.44 (SE14, 0.35) Access Level) in any
menu.
Figure 2-5 User security open
2.7.2 Setting user security
Enter a value between 1 and 999 in Pr 11.30 and press the button;
the security code has now been set to this value. To activate the
security, the access level must be set to Loc in Pr 11.44 (SE14, 0.35).
When the drive is reset, the security code will have been activated and
the drive returns to access level L1. The value of Pr 11.30 will return to 0
in order to hide the security code. At this point, the only parameter that
can be changed by the user is the access level Pr 11.44 (SE14, 0.35).
2.7.3 Unlocking user security
Select a read write parameter to be edited and press the button; the
upper display will now show CodE.
Use the arrow buttons to set the security code and press the button.
With the correct security code entered, the display will revert to the
parameter selected in edit mode. If an incorrect security code is entered
the display will revert to parameter view mode.
To lock the user security again, set Pr 11.44 (SE14, 0.35) to Loc and
press the reset button.
2.7.4 Disabling user security
Unlock the previously set security code as detailed above. Set Pr 11.30
to 0 and press the button. The user security has now been
disabled, and will not have to be unlocked each time the drive is
powered up to allow read / write access to the parameters.
2.8 Alarm and trip display
An alarm can flash alternately with the data displayed on the 2nd row
when one of the following conditions occur. If action is not taken to
eliminate the alarms except "Auto tune" and "PLC", the drive may
eventually trip. Alarms flash once every 640 ms except "PLC" which
flashes once every 10 s. Alarms are not displayed when a parameter is
being edited.
When a trip occurs the drive switches to status mode and "tr" or "trip" is
shown on the 1st row and the trip string flashes on the 2nd row. The read
only parameters listed below are frozen with any trip except UV trip until
the trip is cleared. For a list of the possible trip strings see Pr 10.20 {tr01,
0.51}. Pressing any of the parameter keys changes the mode to the
parameter view mode. If the trip is HF01 to HF16 then no key action is
recognized.
Parameter
access level
User security Menu 0 status
Advanced
menus status
L1 Open Sub block RW Not visible
L1 Closed Sub block RO Not visible
L2 Open Linear RW RW
L2 Closed Linear RO RO
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.90
Pr 1.00
Pr 1.01
Pr 1.02
Pr 1.03
Pr 1.50
Pr 1.51
............
............
............
............
............
............
............
............
Pr 0.00
Pr 0.01
Pr 0.02
Pr 0.03
Pr 0.89
Pr 0.90
Pr 1.00
Pr 1.01
Pr 1.02
Pr 1.03
Pr 1.50
Pr 1.51
Pr 23.00
Pr 23.01
Pr 23.02
Pr 23.03
Pr 23.10
Pr 23.11
............
............
............
............
............
............
............
............
User security open
- All parameters: Read / Write access
User security closed
- All parameters: Read Only access
(except Pr ( )
11.44 SE14, 0.35
Pr 23.00
Pr 23.01
Pr 23.02
Pr 23.03
Pr 23.10
Pr 23.11
Pr 0.49
Pr 22.00
Pr 22.01
Pr 22.02
Pr 22.03
Pr 22.39
Pr 22.40
Pr 22.00
Pr 22.01
Pr 22.02
Pr 22.03
Pr 22.39
Pr 22.40
Alarm
string
Alarm condition
OVLd
Motor overload (Pr 4.19 > 75 % and the drive output
current > Pr 5.07 {SE07, 0.28})
hot Heatsink alarm is active
Autotune Autotune in progress
PLC On-board application lite program is running
CLt Current limit active
S.OV
The suppressor voltage is with in 30 volts of the HF18
trip level. User needs to fit an external suppressor
resistor.
S.rS
External suppressor overload. Active when Pr 11.56 is
greater than 75 %.
ESt SPd Estimated speed selected
Menu 0 Parameter Description Display
0.36 1.01 Speed reference selected di01
1.02 Pre-skip filter reference
0.37 1.03 Pre-ramp reference di02
0.38 2.01 Post ramp reference di03
0.39 3.01 Final speed reference di04
0.40 3.02 Speed feedback di05
3.03 Speed error
0.41 3.04 Speed controller output di06
0.43 4.01 Current magnitude di08
5.01 Armature firing angle
0.45 5.02 Armature voltage di10
5.03 Output power
5.04 Estimated speed
5.05 Line voltage
5.58 Field firing angle
0.82 7.01 Analog input 1 in02
0.83 7.02 Analog input 2 in03
0.84 7.03 Analog input 3 in04
10.77 Input frequency
