5.11 Menu 10: Status and trips

Indicates the drive is not in the trip state. If Pr 10.36 is one and auto-reset is being used, this bit is not cleared until all auto-resets have been

attempted and the next trip occurs. The control board LED reflects the state of this parameter: LED on continuously = 1, LED flashing = 0.

Indicates that the armature is active.

Indicates that the absolute value of speed feedback (Pr 3.02 = {di05, 0.40}) is at or below the zero speed threshold defined by Pr 3.05.

In bipolar mode (Pr 1.10 = 1) this parameter is the same as zero speed (Pr 10.03). In unipolar mode this parameter is set if the absolute value of the

speed feedback (Pr 3.02 = {di05, 0.40}) is at or below (minimum speed + 5 rpm). Minimum speed is defined by (Pr 1.07 = {SE01, 0.22}). The

parameter is only set if the drive is running.

The speed detector in menu 3 sets these flags. (See Pr 3.06, Pr 3.07 and Pr 3.09).

Indicates that the absolute value of the active current is greater or equal to the rated motor current as defined in menu 5.

10.01 Drive OK

Coding
