Parameter

structure

Keypad and

display

Parameter x.00

Parameter description

format

Advanced parameter

descriptions

Serial comms

protocol

Performance

Menu 10

Mentor MP Advanced User Guide 131

Issue Number: 4 www.controltechniques.com

Indicates that the current limits are active.

Indicates that power is being transferred from the motor to the supply.

This parameter is one if the pre-ramp reference (Pr 1.03 = {di02, 0.37}) is negative, and zero if the pre-ramp reference is zero or positive.

This parameter is one if the speed feedback (Pr 3.02 = {di05, 0.40}) is negative, or zero if the speed feedback is zero or positive.

This parameter is set if the drive output current is larger than 105 % of rated current (Pr 5.07 = {SE07, 0.28}) and the overload accumulator is greater

than 75 % to warn that if the motor current is not reduced the drive will trip on an Ixt overload. (If the rated current (Pr 5.07 = {SE07, 0.28}) is set to a

level above the rated drive current (Pr 11.32) the overload alarm is given when the current is higher than 100 % of rated current.)

Indicates that the heat sink temperature Pr 7.04 is above the alarm level.

Indicates that one of the drive alarms is active, i.e. Pr 10.19 = Pr 10.17 OR Pr 10.18.

10.09 Drive output is at current limit

Coding
