Exception message format
The slave exception message has the following format.
Exception codes
The following exception codes are supported.
Parameter over range during block write FC16
The slave processes the write block in the order the data is received. If a
write fails due to an out of range value then the write block is terminated.
However, the slave does not raise an exception response, rather the
error condition is signalled to the master by the number of successful
writes field in the response.
Parameter over range during block read/write FC23
There will be no indication that there has been a value out of range
during a FC23 access.
6.2.9 CRC
The CRC is a 16bit cyclic redundancy check using the standard CRC-16
polynomial x16 + x15 + x2 + 1. The 16bit CRC is appended to the
message and transmitted LSB first.
The CRC is calculated on ALL the bytes in the frame.
6.2.10 Device compatibility parameters
All devices have the following compatibility parameters defined:
Byte Description
0 Slave source node address
1 Original function code with bit7 set
2 Exception code
3CRC LSB
4CRC MSB
Code Description
1 Function code not supported
2
Register address out of range, or request to read too many
registers
Parameter Description
Device ID Unique device identification code
Minimum slave response
time
Maximum slave response
time
When global addressing, the master
must wait for this time before issuing a
new message. In a network of devices,
the slowest time must be used
Maximum baud rate
32bit float data type
supported
If this data type is not supported then an
over range error will be raised if this data
type is used
Maximum buffer size Determines the maximum block size.
