Mentor MP Advanced User Guide 203
Issue Number: 4 www.controltechniques.com
5.26 32 bit parameters
All parameters in the drive are 1 bit, 16 bit or 32 bit. This section identifies all the 32 bit parameters in the drive and Solution Modules.
5.26.1 Drive parameters
The table below contains all the 32 bit parameters present in the drive.
Table 5-11 32 bit drive parameters
Some of the parameters listed above are only 32 bit parameters in certain modes.
5.26.2 Solutions Module parameters
Some Solutions Modules contain 32 bit parameters. Below is a table listing these parameters and the modules in which they are 32 bit parameters
Table 5-12 32 bit Solution Module parameters
Table 5-13 32 bit SM-Applications Plus, SM-Applications and SM-Applications Lite parameters
Menu 32-bit parameters
Menu 1
Pr 1.01 =
{di01, 0.36}
Pr 1.02
Pr 1.03 =
{di02, 0.37}
Pr 1.04
Pr 1.06 =
{SE02, 0.23}
Pr 1.07 =
{SE01, 0.22}
Pr 1.17 Pr 1.18
Pr 1.21 Pr 1.22 Pr 1.23 Pr 1.24 Pr 1.25 Pr 1.26 Pr 1.27 Pr 1.28
Pr 1.36 Pr 1.37 Pr 1.39
Menu 2
Pr 2.01 =
{di03, 0.08}
Pr 2.07
Pr 2.11
{SE04, 0.25}
Pr 2.12 Pr 2.13 Pr 2.14 Pr 2.15 Pr 2.16
Pr 2.17 Pr 2.18 Pr 2.19 Pr 2.21 Pr 2.22 Pr 2.23 Pr 2.24 Pr 2.25
Pr 2.26 Pr 2.27 Pr 2.28 Pr 2.29
Menu 3
Pr 3.01 =
{di04, 0.39}
Pr 3.02 =
{di05, 0.40}
Pr 3.03
Pr 3.10 =
{SP01, 0.61}
Pr 3.18 Pr 3.22
Pr 3.27 =
{Fb09, 0.79}
Menu 4
Pr 4.01 =
{di08, 0.43}
Pr 4.02 Pr 4.08 Pr 4.17
Menu 5 Pr 5.01 Pr 5.03 Pr 5.04
Pr 5.07 =
{SE07, 0.28}
Pr 5.08 =
{SE08, 0.29}
Pr 5.24 Pr 5.25
Menu 11 Pr 11.32
Menu 20
Pr 20.21 Pr 20.22 Pr 20.23 Pr 20.24 Pr 20.25 Pr 20.26 Pr 20.27 Pr 20.28
Pr 20.29 Pr 20.30 Pr 20.31 Pr 20.32 Pr 20.33 Pr 20.34 Pr 20.35 Pr 20.36
Pr 20.37 Pr 20.38 Pr 20.39 Pr 20.40
Menu 21 Pr 21.01 Pr 21.02 Pr 21.04 Pr 21.05 Pr 21.07 Pr 21.08 Pr 21.14 Pr 21.24
Parameter Solutions modules in which the parameter is 32 bit
Pr x.03 SM-Universal Encoder Plus
Pr x.20 SM-Universal Encoder Plus
Pr x.35 All Fieldbus modules
Pr x.48 SM-Applications Plus
Menu 32-bit parameters
Menu 70
to
Menu 75
Pr 70.00
to
Pr 70.99
Pr 71.00
to
Pr 71.99
Pr 72.00
to
Pr 72.99
Pr 73.00
to
Pr 73.99
Pr 74.00
to
Pr 74.99
Pr 75.00
to
Pr 75.99
Menu 90
Pr 90.01 Pr 90.03 Pr 90.19 Pr 90.25 Pr 90.29 Pr 90.31 Pr 90.32 Pr 90.33
Pr 90.34 Pr 90.35 Pr 90.37 Pr 90.38 Pr 90.49
Menu 91
Pr 91.02 Pr 91.03 Pr 91.04 Pr 91.05 Pr 91.06 Pr 91.17 Pr 91.18 Pr 91.19
Pr 91.20
Menu 100
to
Menu 105
Pr 100.00 to
Pr 100.99
Pr 101.00 to
Pr 101.99
Pr 102.00 to
Pr 102.99
Pr 103.00 to
Pr 103.99
Pr 104.00 to
Pr 104.99
Pr 105.00 to
Pr 105.99
Menu 130
to
Menu 135
Pr 130.00
to
Pr 130.99
Pr 131.00 to
Pr 131.99
Pr 132.00 to
Pr 132.99
Pr 133.00 to
Pr 133.99
Pr 134.00 to
Pr 134.99
Pr 135.00 to
Pr 135.99
Menu 160
to
Menu 165
Pr 160.00 to
Pr 160.99
Pr 161.00 to
Pr 161.99
Pr 162.00 to
Pr 162.99
Pr 163.00 to
Pr 163.99
Pr 164.00 to
Pr 164.99
Pr 165.00 to
Pr 165.99
