Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 23
Mentor MP Advanced User Guide 201
Issue Number: 4 www.controltechniques.com
When this parameter is set to 1 the associated pre-defined sub block is
accessible. When this parameter is 0 the associated pre-defined block is
bypassed.
5.23 Pre-Defined Sub Blocks
set-up
Diagnostic
Trips
Speed loop
Serial interface
Speed feedback
23.03 to 23.09 Pre defined sub block enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 to 1
Default 1
Update rate Background read
Parameter Description Display
23.03 setup SEt UP
23.04 Diagnostics diAGnoS
23.05 Trips triPS
23.06 Speed Loop SP LOOP
23.07 Serial interface SintEr
23.08 Speed Feedback Fb SP
23.09 IO InPut
Menu 0 Parameter Description Display
0.21 1.00 Parameter 0 SE00
0.22 1.07 Minimum reference clamp SE01
0.23 1.06 Maximum reference clamp SE02
0.24 2.11 Acceleration rate SE03
0.25 2.21 Deceleration rate SE04
0.26 1.14 Reference selector SE05
0.27 5.09 Armature rated voltage SE06
0.28 5.07 Motor rated current SE07
0.29 5.08 Base speed SE08
0.30 11.42 Parameter copying SE09
0.31 5.70 Rated field current SE10
0.32 5.73 Rated field voltage SE11
0.33 5.77 Enable field control SE12
0.34 5.12 Autotune SE13
0.35 11.44 Security status SE14
Menu 0 Parameter Description Display
0.36 1.01 Speed reference selected di01
0.37 1.03 Pre-ramp reference di02
0.38 2.01 Post ramp reference di03
0.39 3.01 Final speed reference di04
0.40 3.02 Speed feedback di05
0.41 3.04 Speed controller output di06
0.42 4.03 Torque demand di07
0.43 4.01 Current magnitude di08
0.44 5.56 Field current feedback di09
0.45 5.02 Armature voltage di10
0.46 1.11 Reference enabled indicator di11
0.47 1.12 Reverse selected indicator di12
0.48 1.13 Jog selected indicator di13
0.49 11.29 Software version di14
0.50 0.00 Spare
Menu 0 Parameter Description Display
0.51 10.20 Trip 0 tr01
0.52 10.21 Trip 1 tr02
0.53 10.22 Trip 2 tr03
0.54 10.23 Trip 3 tr04
0.55 10.24 Trip 4 tr05
0.56 10.25 Trip 5 tr06
0.57 10.26 Trip 6 tr07
0.58 10.27 Trip 7 tr08
0.59 10.28 Trip 8 tr09
0.60 10.29 Trip 9 tr10
Menu 0 Parameter Description Display
0.61 3.10
Speed controller
proportional gain
SP01
0.62 3.11
Speed controller integral gain SP02
0.63 3.12
Speed controller differential
feedback gain
SP03
0.64 0.00 Spare
0.65 0.00 Spare
Menu 0 Parameter Description Display
0.66 11.25 Baud rate Si01
0.67 11.23 Serial address Si02
0.68 0.00 Spare
0.69 0.00 Spare
0.70 0.00 Spare
Menu 0 Parameter Description Display
0.71 3.26 Speed feedback selector Fb01
0.72 3.51
Tachometer rating (V/1000
rpm)
Fb02
0.73 3.53 Tachometer input mode Fb03
0.74 3.52
Tachometer speed
feedback
Fb04
0.75 3.34
Drive encoder lines per
revolution
Fb05
0.76 3.36 Encoder supply Fb06
0.77 3.38 Encoder type Fb07
0.78 3.39 Encoder termination select Fb08
0.79 3.27 Encoder speed feedback Fb09
0.80 0.00 Spare
