RS flip flop
D-type flip-flop
Reset
(source 2)
Set
(source 1)
Output
10 0
01 1
0 0 No change
Clock
(source 2)
Data
(source 1)
Output
0 X No change
0->1 0 0
0->1 1 1
1 X No change
1->0 X No change
