Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 9
Mentor MP Advanced User Guide 123
Issue Number: 4 www.controltechniques.com
Figure 5-28 Menu 9 logic diagram: Motorized pot and binary sum
Menu 9 contains two logic block functions (which can be used to produce any type of two input logic gate, with or without a delay), a motorized pot
function and a binary sum block. One menu 9 or one menu 12 function is executed every 4 ms. Therefore the sample time of these functions is 4 ms
x number of menu 9 and 12 functions active. The logic functions are active if one or both the sources are routed to a valid parameter. The other
functions are active if the output destination is routed to a valid unprotected parameter.
9.30
Binary-sum
logic twos
9.29
Binary-sum
logic ones (LSB)
9.31
Binary-sum
logic fours (MSB)
9.32
Binary-sum
logic output
value
??.??
Any
unprotected
bit
parameter
??.??
9.33
Binary-sum
logic
destination
parameter
Σ
9.24
Motorized
pot.
output scale
9.25
Motorized
pot.
destination
parameter
9.23
Motorized
pot. rate
??.??
Any
unprotected
variable
parameter
??.??
9.27
Motorized pot.
down
9.26
Motorized pot.
up
M
9.03
Motorized pot.
output
indicator
9.22
Motorized
pot. bipolar
select
9.21
9.28
Motorized pot.
reset to zero
Motorized pot.
mode
+
+
9.34
Binary-sum
offset
0.XX
0.XX
Key
Read-write
(RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
Function disabled if set
to a non valid destination
Function disabled if set
to a non valid destination
