Control Techniques Mentor MP User Manual

Parameter
structure
Keypad and
display
Parameter x.00
Parameter description
format
Advanced parameter
descriptions
Serial comms
protocol
Performance
Menu 21
Mentor MP Advanced User Guide 195
Issue Number: 4 www.controltechniques.com
21.23 Rated field voltage
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 500 Vdc
Default Eur: 360, USA: 300
Normal
parameter
Pr 5.73 = {SE11, 0.32}
Update rate Background read
21.24 Rated field current
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
12 1 111
Range 0 to FIELD_CURRENT_SET_MAX
Default
Size 1 - Eur: 2A, USA: 8A
Size 2A&B - Eur: 3A, USA: 20A
Size 2C&D - Eur: 5A, USA: 20A
Normal
parameter
Pr 5.70 = {SE10, 0.31}
Update rate Background read
21.25 Motor saturation breakpoint 1
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 100 % of rated flux
Default 50
Normal
parameter
Pr 5.29
Update rate Background read
21.26 Motor saturation breakpoint 2
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 100 % of rated flux
Default 75
Normal
parameter
Pr 5.30
Update rate Background read
21.27 Motoring current limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range 0 to MOTOR2_CURRENT_LIMIT_MAX %
Default 150.0*
Normal
parameter
Pr 4.05
Update rate Background read
