The firing angle end stop may be too close to the voltage crossover point. Parameter allows the user to increase the safety margin during
regeneration but the maximum regenerated armature voltage will be reduced.
When 0, the armature voltage is a measurement which is dependent on the setting of Pr 5.16.
When 1, the armature voltage is measured across motor terminals MA1 and MA2.
This parameter is used to scale the current demand such that the control loop correctly predicts the firing angle in the discontinuous current region.
This should be automatically setup by autotune.
Pr 5.15 = 29.5 x V rms / (L x f x Imax)
Where :
L is the load inductance in Henries
R is the load resistance in ohms
f is the supply frequency in Hertz
Imax is the peak load current (including any overload) in amps
V rms is the line-to-line supply voltage in volts.
The source for the armature voltage feedback is determined as follows:
5.13 Continuous back end stop
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
1111
Range 0 to 165.0 deg
Default 165.0 deg
Update rate Background read
5.14 Armature voltage select
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
5.15 Motor constant
Coding
Bit SP FI DE TE VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 to 100.0 %
Default 50 %
Second motor
parameter
Pr 21.11
Update rate Background read
5.16 DC contactor
Coding
BitSP FI DETEVMDPNDRANCNVPTUSRWBUPS
111
Default 0
Update rate Background read
Pr 5.14 Pr 5.16 Pr 6.55 Armature voltage selected
00 0 A1, A2
00 1 MA1, MA2
01 0 A1, A2
01 1
MA1, MA2
10 0
10 1
11 0
11 1
