Menu 5
Parameter
structure
Keypad and
display
Parameter x.00
Parameter
description format
Advanced parameter
descriptions
Serial comms
protocol
Performance
84 Mentor MP Advanced User Guide
www.controltechniques.com Issue Number: 4
Figure 5-13 Multiple slaves 1 monitor bit
Set Pr 8.22 to Pr 5.45.
Figure 5-14 Multiple Slaves signal multiple monitor Bits
Set Pr 8.22 to Pr 5.45, Pr 8.25 to Pr 5.46 and Pr 8.26 to Pr 5.47.
Slave
51 52 53
NC
Master
51 52 53
NC
25
Slave
51 52 53
NC
Slave
51 52 53
NC
22
Slave
51 52 53
NC
Master
51 52 53
25
Slave
51 52 53
NC
Slave
51 52 53
NC
22
22
22
2829
