10-8 Parameters
Parameter Description
#91.06 Speed feedback (#3.2)
Use #91.06 only when the Drive is used in closed loop.
Units: 0.01
RPM (eg. 123 represents 1.23 RPM)
Update rate: L3
#91.07 Current feedback (#4.02)
Units: 0.01 A (eg. 100 represents 1.00A)
Update rate: L3
#91.08 Analog input 1 value
Scaled for ±4000 to represent ±[full scale] signal at the input.
Update rate: L3
#91.09 Analog input 2 value
Scaled for ±1000 to represent ±[full scale] signal at the input.
Update rate: L3
#91.10 Analog input 3 value
Scaled for ±1000 to represent ±[full scale] signal at the input.
Update rate: L3
Update rates
Code PWM switching frequency
3, 6, 12 kHz 4.5, 9 kHz
L2 345 µs460 µs
L3 1.38 ms 1.84 ms
Menus 70 to 73
These menus refer to the PLC register-set, as follows:
#70.xx _Px%
#71.xx _Qx%
#72.xx _Rx%
#73.xx _Sx%
Where x is a value from 0 to 99.
