Control Techniques UD70 User Manual

UD70
Issue code: 70nu2
5-16 DPL toolkit
Saving the
Watch
window
settings
The settings of the WatchWatch window can be saved onto disk for later use. To
achieve this, select SaveSave in the FileFile menu of the WatchWatch window.
Further details of the WatchWatch window are covered in the on-line help facility.
Press F1 at any time to display the on-line help.
Uploading the DPL source file
from the UD70 to the host PC
The .DPL source file can be uploaded to the host PC when the original
program file is not available or if the program that is running is not
exactly known.
Use the following procedure to retrieve the .
DPL file:
1 Click on (UploadUpload ) in the DPL Task Manager toolbar. If a
version of the
DPL program already exists in the host PC, a dialog box
appears asking if the file is to overwritten.
2 To find out which program is resident in the UD70, and to attempt to
load it, click on:
(Source codeSource code)
Important Note
It is safer to upload the *.DPL program from the UD70 than
to retrieve the source code from the host PC, unless you
are sure that the program that is in the host is the
required program.
