Scanning Electron Microscope EM-30PLUS Operating Manual
30
 Height of Sample
To prevent collisions when using Tilt function, it helps limit the maximum angle of tilt
automatically by inputting the height of Sample Holder. (The maximum angle of Tilt is as
shown in the table below.)
X (mm)
Y (mm)
Sample Holder
Height (mm)
Maximum Angle of
Tilt( °)
17.5
17.5
42.5
18
17.5
17.5
40
20
17.5
17.5
35
22
17.5
17.5
30
25
17.5
17.5
25
29
17.5
17.5
20
34
17.5
17.5
15
42
17.5
17.5
13
45
 When X, Y coordinate is not in the Center(17.5mm, 17.5mm), it can be limited more
than the maximum angle of Tilt.
 In case of WD 50mm Sample Mount, when Sample is not installed, the Sample Holder
Height is 0mm.
