CSC TT250 - Starting System

TT250Owner’s andServiceManual
www.CSCMotorcycles.com
112

Unbolttheharnessretainerfromthecrankcase.

Removethestartermotortransfergearcover.

Removethestartertransfergears.Notetheirorientation;
thesmallergearisclosesttothestartermotor.Notethat
therearesmallshimsoneithersideofthegearcluster;take
carenottolosethem.


Unboltthe8mmboltsecuringthestartergeartransfercase
tothecrankcase.Notethatthisboltisafullythreadedbolt.

Gentlyprytheleftcrankcaseenginecoverfromtheengine.
