IftheengineisnotprovidingtheappropriateoutputAC
voltageortheresistancebetweenthestatorleadsistoohigh
(asmeasuredattheconnectorshownearlier),thereisa
problemwiththestator,theengine’sinternalwiringfrom
thestator,ortherotor.Itwillbenecessarytoremove
the
leftenginecrankcasecovertoinspectandcorrectthe
anomalouscondition.

Placeadrippanbeneaththeengine,asoilwillescapefrom
theengineduringthisoperation,andremovethegearshift
leverwitha10mmwrench.

Thereareseveral8mmboltssecuringtheleftenginecover
and
thecountershaftsprocketcover.Removeall of
them.Notethattheboltsareofdifferentlengths.Takecare
tonotewhereeachboltisused.

Removethecountershaftsprocketcover.

Disconnectthestatorharness.

