CSC TT250 - Page 117

To Next Page

To Previous Page

TT250Owner’s andServiceManual

www.CSCMotorcycles.com

116



Removethecountershaftsprocketcover.

Removethechargingcircuitharnessretentionclip.

Disconnectthechargingcircuitconnectorplug.

Unboltthe8mmboltinsidethestartermotortransfercase.

Gentlyremovetheleftenginecrankcasecover.
