3-2
3. SPECIFICATIONS
Sc2400 Operator’s Manual
Traveling
System
Tire
Ag (R1)
Front 18 × 8.50-10
Rear 26 × 12.00-12
Turf (R3)
Front 18 × 8.50-10
Rear 26 × 12.00-12
Industrial (R4)
Front 18 × 8.50-10
Rear 26 × 12.00-12
Clutch –
Steering Power Steering
Transmission
Hydrostatic Transmission,
2 Range Speeds
Drive Selected 4WD
Brake Wet plates
Minimum Turning Radius ft (m) 7.2 (2.2)
Differential Lock Foot Pedal Control
Hydraulic Unit
Hydraulic Control System Type Position Control
Pump Capacity (main)
US gal/min
(L/min)
Approximately 3.4 (13.2)
Pump Capacity (steering)
US gal/min
(L/min)
Approximately 3.4 (13.2)
3-Point Hitch Limited Category I
Max. Lift Force
Lift Point lb. (kg) 1036 (470)
24 in. Behind Lift Point lb. (kg) 661 (300)
System Pressure psi (MPa) 1813 (12.5)
Power Take Off
(PTO)
Type Electric Clutch
Rear
Shaft Size SAE 1-3/8, 6-Splines
Type Independent
Speed / Engine rpm 540 / 3111
Mid
Shaft Size SAE 16/32, 15-Splines
Type Independent
Speed / Engine rpm 2100 / 3338
2. Traveling Speeds
Model Sc2400
Range Shift Lever mph km/h
Forward
Slow 0-6.0 0-9.7
Fast 0-9.3 0-15
Reverse
Slow 0-3.6 0-5.8
Fast 0-5.6 0-9
