4-1
4. IMPLEMENT CAPACITIES
Sc2400 Operator’s Manual
4. IMPLEMENT CAPACITIES
The Cub Cadet Yanmar tractor has been carefully tested in the configuration equipped with implements sold or
approved by Cub Cadet Yanmar and has proved to perform properly. Do not use any implement that has not
been sold or recommended by a Cub Cadet Yanmar dealer, or that fails to satisfy the specified values given
below. Never mount an implement that is not approved for the Cub Cadet Yanmar tractor. Using unapproved
implements could result in malfunction, failure, and damage to the tractor and/or implement, and increase the
possibility of injury to the operator or other people. The Cub Cadet Yanmar warranty does not cover any
malfunction or failure that results from use of an unapproved implement.
NOTE:
●Backhoes cannot be attached.
24in. Behind Lift Point
Maximum
Lifting Capacity
Implement Weight
Maximum Vertical
Hitch Load
Maximum
Towing Capacity
W
0
W
1
W
2
W
3
lb 661
As specified in the list
below.
331 661
kg 300 150 300
Implement Remarks Unit Amount
Front - End Loader
Maximum Lift Capacity (at Pivot) lb (kg) 700 317
Maximum Overhang (Pivot - Front Tire Center) in. (mm) 40 1022
Maximum Weight lb (kg) 441 200
Maximum Oil Pressure psi (MPa) 1885 13
Mower
Mid - Mount
Maximum Cutting Width in. (mm) 60 1524
Maximum Weight lb (kg) 254 115
Rear - Mount
Maximum Cutting Width in. (mm) 48 1219
Maximum Weight lb (kg) 351 159
Rotary Tiller
Maximum Tilling Width in. (mm) 42 1067
Maximum Weight lb (kg) 342 155
Box Scraper (Box Blade)
Maximum Cutting Width in. (mm) 48 1219
Maximum Weight lb (kg) 254 115
Rear Blade
Maximum Cutting Width in. (mm) 60 1524
Maximum Weight lb (kg) 176 80
A3013714a

Cub Cadet Yanmar SC2400 Specifications

General

Engine Power	24 hp
Transmission Type	Hydrostatic
Fuel Capacity	6.6 gallons
Drive	4WD
PTO	Independent
Hydraulic System	Open center
3-Point Hitch	Category 1
Engine Type	3TNV76 diesel engine
