Cub Cadet Yanmar SC2400 User Manual

7-8
7. OPERATING THE ENGINE
Sc2400 Operator’s Manual
1. Remove foot from the forward and
reverse drive pedal.
2. After the tractor has completely
stopped, turn off the Power Take Off
(PTO) switch, lower the implement (if
installed) to the ground and then
engage the parking brake securely.
3. Run the engine at a lowest possible
speed for at least 2 minutes.
4. Turn the key to the OFF position.
5. Remove the key from the starter key
switch.
6. Make sure that the engine and other
components have stopped running.
NEVER leave the operator’s seat
while any components are running.
(A) Forward and reverse drive pedal
(B) Throttle control lever
(C) Power Take Off (PTO) switch
2. Stopping the Engine
3013703a
(B)
(A)
3014919c
(C)

Cub Cadet Yanmar SC2400 Specifications

General

Engine Power	24 hp
Transmission Type	Hydrostatic
Fuel Capacity	6.6 gallons
Drive	4WD
PTO	Independent
Hydraulic System	Open center
3-Point Hitch	Category 1
Engine Type	3TNV76 diesel engine
