Cub Cadet Yanmar SC2400 User Manual

9-2
9. POWER TAKE OFF (PTO)
Sc2400 Operator’s Manual
■ Rear- Power Take Off (PTO)
(A) Rear- Power Take Off (PTO) shaft
■ Mid- Power Take Off (PTO)
(A) Mid- Power Take Off (PTO) shaft
■ Engaging the Power Take Off (PTO)
NOTE:
●This tractor cannot drive the Power Take Off (PTO)
unless the operator sits on the seat. When the
operator leaves the seat while the Power Take Off
(PTO) is engaged, the safety interlock system
stops the implement and the engine.
●Normally, reversing the tractor stops the Mid-
Power Take Off (PTO) and the Rear-Power Take
Off (PTO). To drive the Power Take Off (PTO)
while reversing the tractor, use the reverse-
override-switch.
(A) Reverse-override-switch
P3014908
(A)
3014919d
(A)
3014919d
(A)

Cub Cadet Yanmar SC2400 Specifications

General

Engine Power	24 hp
Transmission Type	Hydrostatic
Fuel Capacity	6.6 gallons
Drive	4WD
PTO	Independent
Hydraulic System	Open center
3-Point Hitch	Category 1
Engine Type	3TNV76 diesel engine
