9-4
9. POWER TAKE OFF (PTO)
Sc2400 Operator’s Manual
8. While watching the instrument panel, adjust the
engine speed suitable for operating with the
throttle control lever.
(A) Throttle control lever
NOTE:
●When the engine speed is 3300 rpm, the Mid-
Power Take Off (PTO) rotates at approximately
2100 rpm.
●When the engine speed is 3100 rpm, the Rear-
Power Take Off (PTO) rotates at approximately
540 rpm.
■ Disengaging the Power Take Off (PTO)
1. Run the engine at a low speed.
2. Push in the Power Take Off (PTO) switch to set it
to the OFF position.
(A) Power Take Off (PTO) switch
(a) ON position
(b) OFF position
3014903e
(A)
3014919c
(A)
(b)
(a)
To Next Page
