TABLE 4−31. ANALOG CIRCUIT BOARD (A33) INPUTS AND OUTPUTS
Input Name Input
Connection
Input Signal
Range
Output Name
1
Output
Connection
2
Output
Signal Range
L1 (0 to nominal) J4-24 to J4-28 0 to 18 VAC L10 (ACH1) J2-4 0 to 3.0 VDC
L2 (0 to nominal) J4-26 to J4-28 0 to 18 VAC L20 (ACH2) J2-13 0 to 3.0 VDC
L3 (0 to nominal) J4-30 to J4-28 0 to 18 VAC L30 (ACH3) J2-1 0 to 3.0 VDC
3PH ave (ACH0) J2-18 0 to 2.9 VDC
Line freq. (HSI.1) J2-21 0-5V sq wave @ L1 Hz
CT21 (0 to full load) J4-33 to J4-34 0 to 1.65 VAC C1 fltrd (ACH4) J2-3 0 to 1.0 VDC
CT22 (0 to full load) J4-32 to J4-34 0 to 1.65 VAC C2 fltrd (ACH5) J2-9 0 to 1.0 VDC
CT23 (0 to full load) J4-31 to J4-34 0 to 1.65 VAC C3 fltrd (ACH6) J2-17 0 to 1.0 VDC
C1 (ACH7) J2-7 0 to 1.0 VDC
C2 (ACH7) J2-7 0 to 1.0 VDC
C3 (ACH7) J2-7 0 to 1.0 VDC
(1 to 0.8 pf) Phase angle 1 (ACH7)
3
J2-7 0 to 1.0 VDC
(1 to 0.8 pf) Phase angle 2 (ACH7)
3
J2-7 0 to 1.0 VDC
(1 to 0.8 pf) Phase angle 3 (ACH7)
3
J2-7 0 to 1.0 VDC
(L1 vs CT21) Lead lag (P2A.1))
3
J2-29 0 or 5 VDC (digital)
Bus L1 (0 to nominal)
6
J4-15 to J4-18 0 to 18 VAC Bus L1 (ACH7) J2-7 0 to 3.0 VDC
Bus L2 (0 to nominal)
6
J4-16 to J4-18 0 to 18 VAC Bus L2 (ACH7) J2-7 0 to 3.0 VDC
Bus L3 (0 to nominal)
6
J4-17 to J4-18 0 to 18 VAC Bus L3 (ACH7) J2-7 0 to 3.0 VDC
Bus freq (HS1.3) J2-22 0-5V sq wave @ Bus L1 Hz
Phase rot (P2A.0)
5
J2-26 0 or 5 VDC (digital)
Bus/gen phase dif (ACH7)
5
J2-7 0 to 5.0 VDC
Bus/gen phase (HS1.2)
5
J2-19 0-5V 120 Hz 0 to 100% DC
Synch (ACH7)
5
J2-7
Battery voltage J1-31 (+) to J1-30(−) 0 to 32 VDC Battery voltage (ACH7) J2-7 0 to 2.9 VDC
Oil press (0 to 100 psi) (See note
4 )
0.5 to 4.5 VDC Oil press (ACH7) J2-7 0.5 to 4.5 VDC
H
2
O 1 (6 to 230 F) J1-19/20 to J1-17/18 700 to 1800  H
2
O 1 (ACH7) J2-7 1.4 to 3.7 VDC
H
2
O 2 (6 to 230 F) J1-15/16 to J1-14/15 700 to 1800 H
2
O 2 (ACH7) J2-7 1.4 to 3.7 VDC
Oil temp (6 to 230 F) J1-11/12 to J1-9/10 700 to 1800 Oil temp (ACH7) J2-7 1.4 to 3.7 VDC
Exh temp 1 (32 to 1471 F) J1-7/8 to J1-5/6 100 to 376 Exh temp 1 (ACH7) J2-7 0.8 to 3.0 VDC
Exh temp 2 (32 to 1471 F) J1-3/4 to J1-1/2 100 to 376 Exh temp 2 (ACH7) J2-7 0.8 to 3.0 VDC
Notes:
1. All output signals on ACH7 are multiplexed.
2. All output voltages on A33 J2 are referenced to ground (J2-15 and J2-16).
3. Must have L1, L2, L3, CT21, CT22, and CT23 for these phase angle outputs.
4. J1-24 (5VDC), J1-23 (signal), J1-18 (return).
5. Must have L1, L2, L3, Bus L1, Bus L2, and Bus L3 for these outputs.
6. L1, L2, and L3 can be 0 to 180out of phase with Bus L1, Bus L2, and Bus L3, respectively.
