CUMMINS QST30 - Pcc Fuses

4-46
Copyright  2017 Cummins Inc.
TABLE 4-32. PCC FUSES
LOCATION
REFERENCE
DESIGNATION
RATING FUNCTION
Engine Interface A31-F1 5 Amp PCC control B+
Engine Interface A31-F3 5 Amp Auxiliary B+ (for panel lights, run and start relays)
Governor Output
Module
A38-F4 10 Amp Network B+ (to TB1 customer terminal block)
Governor Output
Module
A38-F3 10 Amp Switched B+ (to TB1 customer terminal block)
Governor Output
Module
A38-F1 15 Amp Left actuator
TB-Bat (Engine
Harness Assembly)
F1 20 Amp Customer B+ (to TB1 customer terminal block)
Governor Output
Module
A38-F2 15 Amp Right actuator
