4 — PROGRAMMABLE PARAMETERS
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 92
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Nominal Resistance
Pot_6_R
0x336C 0x00
800 – 15000 Ohms 5000 Ω Set the potentiometer resistance.
Throttle or Brake potentiometers are typically 1k, 5k, or 10k Ohms.
Note: If this parameter value is outside the actual resistance, it
will trigger a Throttle Input fault (Flash code 0x42) if Throttle_
Source = 6.
Note: If this parameter value is outside the actual resistance, it will
trigger a Brake Input fault (Flash code 0x44) if Brake_Source = 6.
Analog 6 menu
Parameters for 2Wire Pot selection Reference the 2-wire potentiometer throttle section, Chapter 6
Potentiometer 6
Analog 6 Type
Analog_Input_6_Type
0x3310 0x00
2Wire Pot
(selection menu)
– Selection of the 2-Wire Pot opens the Nominal Resistance
parameter.
Note, when conguring Analog input 6 as a 2-Wire Potentiometer
input, pin 15 is both the voltage supply and wiper input. As
a 2-wire pot, one side of the potentiometer is left open (no
connection) and the other end is connected to ground (i.e., pin 7).
The Programmer app will automatically adjust the menu to match
this parameter conguration.
Nominal Resistance
Pot_6_R
0x336C 0x00
800 – 15000 Ohms 5000 Ω Set the nominal resistance of the potentiometer.
Throttle or Brake potentiometers are typically 1k, 5k, or 10k Ohms.
Note: If this parameter value is outside the actual resistance, it
will trigger a Throttle Input fault (Flash code 0x42) if Throttle_
Source = 6.
Note: If this parameter value is outside the actual resistance, it will
trigger a Brake Input fault (Flash code 0x44) if Brake_Source = 6.
Analog 6 menu
Parameters for Voltage with Supply selection
Analog 6 Type
Analog_Input_6_Type
0x3310 0x00
Voltage with Supply
(selection menu)
– The Analog 6 Type “Voltage with Supply” selection operates the
Analog 6 input (pin 15) as a raw voltage input with an internal
pull-up supply voltage.
The output voltage is 10V (approx.) with a 3 mA current limit (to
the external load/device). Reference Table 7.
Use this selection for operating resistive devices such as
thermistors and photocells and reading the voltage in VCL
using the Monitor variable analog_input_volts_6 (0x3B33), then
processing the value in the VCL program.
Voltage
Analog_Input_Volts_6
0x3B33 0x00
–327.68 – 327.67
–32768 – 32767
Read Only
V
The analog voltage at the input pin 15.
Percent
Analog_Input_Percent_6
0x3B3E 0x00
0.0 – 100.0 %
0 – 1000
Read Only
%
The percentage of the voltage at pin 15 based upon the High and
Low settings, i.e., the percent of:
((analog_input_volts_6) – (analog_input_6_low)) /
((analog_input_6_high) – (analog_input_6_low))
Quick Links:
Voltage rottle p.136
3-Wire rottle p.135
2-Wire rottle p.135
Fig. 6 p.10
