4 — PROGRAMMABLE PARAMETERS
pg. 93
Return to TOC Curtis AC F4-A Motor Controller – August 2020
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Low
Analog_Input_6_Low
0x32FD 0x00
0.0 – 11.0 V
0 – 1100
0.0 V The minimum input voltage before a fault is declared. When the
Analog 6 Type selection is Voltage with Supply, this set point
represents the 0% point for the normalized input.
Faults:
When the voltage falls below this parameter, it will trigger the
Analog_6_OUT_OF_RANGE fault (flash code 0xB6, Can Index
0x2625).
If assigning the Throttle to Analog 6, the resulting fault will become
the Throttle Input fault (flash code 0x42, CAN Index 0x2210).
If assigning the Brake to Analog 6, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 6.
High
Analog_Input_6_High
0x32FE 0x00
0.0 – 11.0 V
0 – 110
11.0 V The maximum input voltage before a fault is declared. When
the Analog 6 Type selection is Voltage with Supply, this set point
represents the 100% point for the normalized input.
Faults:
When the voltage rises above this parameter, it will trigger the
Analog_6_OUT_OF_RANGE fault (flash code 0xB6, Can Index
0x2625).
If assigning the Throttle to Analog 6, the resulting fault will become
the Throttle Input fault (flash code 0x42, CAN Index 0x2210).
If assigning the Brake to Analog 6, the resulting fault will become
the Brake Input fault (Flash code 0x44) if Brake_Source = 6.
Analog 7 menu
Voltage
Analog_Input_Volts_7
0x3B34 0x00
–327.68 – 327.67
–32768 – 32767
Read Only
V
Voltage at pin 22.
Percent
Analog_Input_Percent_7
0x3B3F 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis, pin 22.
The percentage of the voltage at pin 22 is based upon the High
and Low settings, i.e., the percent of:
((analog_input_volts_7) – (analog_input_7_low)) /
((analog_input_7_high) – (analog_input_7_low))
Low
Analog_Input_7_Low
0x32FF 0x00
0.0 – 30.0 V
0 – 3000
0.0 V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
High
Analog_Input_7_High
0x3300 0x00
0.0 – 30.0 V
0 – 3000
30.0 V The maximum input voltage before a fault is declared.
This voltage is the 100% point for the normalized inputs.
Analog 8 menu
Voltage
Analog_Input_Volts_8
0x3B35 0x00
–327.68 – 327.67
–32768 – 32767
Read Only
V
Voltage at pin 33.
Percent
Analog_Input_Percent_8
0x32E4 0x00
0.0 – 100.0 %
0 – 1000
Read Only Voltage on a 0-100 percentage basis, pin 33.
The percentage of the voltage at pin 33 based upon the High and
Low settings, i.e., the percent of:
((analog_input_volts_8) – (analog_input_8_low)) /
((analog_input_8_high) – (analog_input_8_low))
Low
Analog_Input_8_Low
0x3307 0x00
0.0 – 30.0 V
0 – 3000
0.0 V The minimum input voltage before a fault is declared.
This voltage represents the 0% point for the normalized inputs.
Quick Links:
Voltage rottle p.136
3-Wire rottle p.135
2-Wire rottle p.135
Fig. 6 p.10
