Curtis Instruments AC F4-A User Manual

4 — PROGRAMMABLE PARAMETERS
pg. 101
Return to TOC Curtis AC F4-A Motor Controller – August 2020
CONTROLLER SETUP/IO ASSIGNMENTS — CONTROLS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Hydraulics Inhibit Type
Hydraulics_Inhibit_Type
0x3702 0x00
0 – 3
0 – 3
0 Prevents accidental turn-on of peripherals at startup/key-cycle.
0 - No inhibit
1 - Lift Only
2 - Lower only
3 - Both
Lift Input Type
Lift_Input_Type
0x3C29 0x00
0 – 3 0
[PCF]
Sets the type of lift input connected.
0 - NO Switch
1 - NC Switch
2 - Voltage Input.
Note, set the respective min, max, map, offset, offset parameters
within the Hydraulics Lift menu)
Lift Input Source
Lift_Input_Source
0x372A 0x00
0 – 32
0 – 32
0
[PCF]
Select which input number to use as lift source.
0: VCL Throttle (range: 0-100)
1-32: Input Number
Note, VCL may require further input mapping setup, see the
Hydraulics Lift menu
Lift Limit Switch Type
Lift_Limit_Type
0x3C3F 0x00
0 – 3
0 – 3
0
[PCF]
Sets the limit switch type.
0-Normally Open(NO) Switch
1-Normally Closed Switch
2-Voltage Input (Turns off Pump if input >50)
Note, set the respective min, max, map, offset, offset parameters
within the Hydraulics Lift menu)
Lift Limit Switch Source
Lift_Limit_Source
0x3C3E 0x00
0 – 32
0 – 32
0
[PCF]
Assign the Lift Input (switch) number.
Lower Input Type
Lower_Input_Type
0x3C3A 0x00
0 – 2
0 – 2
0
[PCF]
Sets the type of Lower input connected.
0-NO Switch
1-NC Switch
2-Voltage Input
Note, set the respective min, max, map, offset, offset parameters
within the Hydraulics Lower menu)
Lower Input Source
Lower_Input_Source
0x372B 0x00
0 – 32
0 – 32
0
[PCF]
Sets the input (switch) number to use as the Lower source.
0: VCL Throttle (range: 0-100)
1-32: Input Number
Note, VCL may require further input mapping setup, see the
Hydraulics Lift menu
