Curtis Instruments AC F4-A User Manual

4 — PROGRAMMABLE PARAMETERS
Curtis AC F4-A Motor Controller – August 2020 Return to TOC
pg. 102
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU
PARAMETER ALLOWABLE RANGE DEFAULT
DESCRIPTION
MONITORS THE CONTROLLER SWITCH STATUS
Switch 1
Switch_1
0x3324 0x00
On/Off
On/Off
Read Only Pin 16
Switch 2
Switch_2
0x3325 0x00
On/Off
On/Off
Read Only Pin 8 (normally = Motor Temp sensor input)
Switch 3
Switch_3
0x3326 0x00
On/Off
On/Off
Read Only Pin 31 (normally = Encoder A input)
Switch 4
Switch_4
0x3327 0x00
On/Off
On/Off
Read Only Pin 32 (normally = Encoder B input)
Switch 5
Switch_5
0x3328 0x00
On/Off
On/Off
Read Only Pin 9
Switch 6
Switch_6
0x3329 0x00
On/Off
On/Off
Read Only Pin 15
Switch 7
Switch_7
0x332A 0x00
On/Off
On/Off
Read Only Pin 22
Switch 8
Switch_8
0x332B 0x00
On/Off
On/Off
Read Only Pin 33
Switch 9
Switch_9
0x332C 0x00
On/Off
On/Off
Read Only Pin 24
Switch 10
Switch_10
0x332D 0x00
On/Off
On/Off
Read Only Pin 10
Switch 11
Switch_11
0x332E 0x00
On/Off
On/Off
Read Only Pin 11
Switch 12
Switch_12
0x332F 0x00
On/Off
On/Off
Read Only Pin 12
Switch 13
Switch_13
0x3330 0x00
On/Off
On/Off
Read Only Pin 14
Switch 14
Switch_14
0x3331 0x00
On/Off
On/Off
Read Only Pin 25
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU
e read only switch inputs On/O status include the inputs on any pins that can process a voltage
reading. Use the on/o status in this menu during setup and application development to verify an
“input” status.
