Curtis Instruments AC F4-A User Manual

4 — PROGRAMMABLE PARAMETERS
pg. 103
Return to TOC Curtis AC F4-A Motor Controller – August 2020
CONTROLLER SETUP/IO ASSIGNMENTS — SWITCH STATUS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT
DESCRIPTION
MONITORS THE CONTROLLER SWITCH STATUS
Switch 18
Switch_18
0x333D 0x00
On/Off
On/Off
Read Only Pin 17
Switch 19
Switch_19
0x333E 0x00
On/Off
On/Off
Read Only Pin 27
Switch 20
Switch_20
0x3339 0x00
On/Off
On/Off
Read Only Pin 1 (the keyswitch, always = On when powered).
Switch 21
Switch_21
0x3332 0x00
On/Off
On/Off
Read Only Pin 2 (when the driver is used as a switch input).
Switch 22
Switch_22
0x3333 0x00
On/Off
On/Off
Read Only Pin 5 (when the driver is used as a switch input).
Switch 23
Switch_23
0x3334 0x00
On/Off
On/Off
Read Only Pin 4 (when the driver is used as a switch input).
Switch 24
Switch_24
0x3335 0x00
On/Off
On/Off
Read Only Pin 3 (when the driver is used as a switch input).
Switch 25
Switch_25
0x3336 0x00
On/Off
On/Off
Read Only Pin 6 (when the driver is used as a switch input).
Switch 26
Switch_26
0x3337 0x00
On/Off
On/Off
Read Only Pin 19 (when the driver is used as a switch input).
Switch 27
Switch_27
0x3338 0x00
On/Off
On/Off
Read Only Pin 20 (when the driver is used as a switch input).
