Curtis Instruments AC F4-A User Manual

5 — SYSTEM MONITOR MENU
pg. 121
Return to TOC Curtis AC F4-A Motor Controller – August 2020
SYSTEM MONITOR MENU: OUTPUTS
VARIABLE DISPLAY RANGE DESCRIPTION
Driver 1 PWM
Driver_1_PWM
0x3402 0x00
0.000 – 100.000 %
0 – 32767
Driver 1 PWM output percentage (pin 2).
Driver 2 PWM
Driver_2_PWM
0x3405 0x00
0.000 – 100.000 %
0 – 32767
Driver 2 PWM output percentage (pin 5).
Driver 3 PWM
Driver_3_PWM
0x3408 0x00
0.000 – 100.000 %
0 – 32767
Driver 3 PWM output percentage (pin 4).
Driver 4 PWM
Driver_4_PWM
0x340B 0x00
0.000 – 100.000 %
0 – 32767
Driver 4 PWM output percentage (pin 3).
Driver 5 PWM
Driver_5_PWM
0x340E 0x00
0.000 – 100.000 %
0 – 32767
Driver 5 PWM output percentage (pin 6).
Driver 1 Current
driver_1_current
0x3400 0x00
–327.68 – 327.67 Amps
–32768 – 32767
Calculated current through Driver 1.
See Driver current rating.
Driver 2 Current
driver_2_current
0x3403 0x00
–327.68 – 327.67 Amps
–32768 – 32767
Calculated current through Driver 2.
See Driver current rating.
Driver 3 Current
driver_3_current
0x3406 0x00
–327.68 – 327.67 Amps
–32768 – 32767
Calculated current through Driver 3.
See Driver current rating.
Driver 4 Current
driver_4_current
0x3409 0x00
–327.68 – 327.67 Amps
–32768 – 32767
Calculated current through Driver 4.
See Driver current rating.
Driver 5 Current
driver_5_current
0x340C 0x00
–327.68 – 327.67 Amps
–32768 – 32767
Calculated current through Driver 5.
See Driver current rating.
External_5V
External_5V_Supply
0x36AA 0x00
0.00 – 100.00 V
0 – 10000
Voltage at +5V output (pin 26).
External_12V
External_12V_Supply
0x36AB 0x00
0.00 – 100.00 V
0 – 10000
Voltage at +12V output (pin 25).
External 5V Current
Ext_5V_Current
0x36AE 0x00
0 – 200 mA
0 – 200
Current (mA) of the external +5V voltage supply (pin 26).
External 12V Current
Ext_12V_Current
0x36AF 0x00
0 – 200 mA
0 – 200
Current (mA) of the external +12V voltage supply (pin 25).
