Curtis 1298 Manual, os 11
NOMINAL 2 MIN TRACTION 1 HOUR TRACTION 2 MIN DC PUMP 1 HOUR DC PUMP
MODEL BATTERY VOLTAGE CURRENT RATING CURRENT RATING CURRENT RATING CURRENT RATING
NUMBER (volts) (amps rms) (amps rms) (amps) (amps)
1298-220X 24 250 165 300 215
1298-230X 24 300 200 350 235
Notes: Internal algorithms automatically reduce maximum current limit when heatsink temperature is >85°C or battery voltage is
outside the allowed limits. Heatsink temperature is measured internally near the power MOSFETs.
2-minute ratings are based on an initial controller heatsink temperature of 25°C and a maximum heatsink temperature
of 85°C. No addtitional external heatsink is used for the 2-minute rating test.
1-hour ratings assume that only one motor (traction or pump) is running for the test. For a combined rating, contact
your Curtis customer support engineer for power dissipation charts.
Table E-1 SPECIFICATIONS: 1298 CONTROLLER
Nominal input voltage 24V
PWM operating frequency 10 kHz
Maximum encoder frequency 10 kHz
Maximum controller output frequency 300 Hz
Electrical isolation to heatsink 500 V ac (minimum)
Minimum pump motor resistance 10 m
Ω
Storage ambient temperature range -40°C to 95°C (-40°F to 203°F)
Operating ambient temp. range -40°C to 50°C (-40°F to 122°F)
Internal heatsink operating temp. range -40°C to 95°C (-40°F to 203°F)
Heatsink overtemperature cutoff linear cutback starts at 85°C (185°F); complete cutoff at 95°C (203°F)
Heatsink undertemperature cutoff complete cutoff at -40°C (-40°F)
Package environmental rating IP65; compliance requires a mating AMPSEAL 35-pin connector header
Weight 2.84 kg (6.3 lbs)
Dimensions (W
× L×H) 155 × 212 × 75 mm (6.1" × 8.3" × 3.0")
EMC Designed to the requirements of EN12895
Safety Designed to the requirements of EN1175
UL UL recognized component per UL583
Note: Regulatory compliance of the complete vehicle system
with the controller installed is the responsibility of the OEM.
E-1
APPENDIX E: SPECIFICATIONS
APPENDIX E
SPECIFICATIONS
