Individual parameters are presented as follows in the menu charts:
3 — PROGRAMMABLE PARAMETERS
Parameter name Allowable range Description of the parameter’s
as it appears in the in the function and, where applicable,
programmer display programmer’s units suggestions for setting it
⇓ ⇓ ⇓
Max Speed 100–8000 rpm Defines the maximum allowed motor rpm at full throttle.
Max_Speed_SpdM 100–8000
⇑ ⇑
Parameter name Allowable range
in VCL in VCL units
Note: All bit variables have two VCL parameter names. The first is the name
of the bit, and the second is the name of the byte containing the bit. The bit
position within the byte is indicated in brackets after the byte name.
Examples:
BIT NAME: Metric_Units
BYTE NAME: OptionBits3 [Bit 5]
BIT NAME: EMR_Dir_Interlock
BYTE NAME: EMR_Dir_Interlock_Bit0 [Bit 0]
In the second example, “_Bit0” is part of the byte name, and does not indicate
the bit position; this byte, like all bytes, has 8 available bits.
Within the menu charts, each pair of bit variable names is shown as a
grouped set, with the bit name appearing first and then the byte name:
Metric Units On/Off
Metric_Units On/Off
OptionBits3 [Bit 5]
To Next Page
