10.1 Paper roll holder
For the device is available an external paper roll holder kit 974AU010000305 (supplied as an accessory). The kit makes it
possible to use paper rolls with larger diameter (up to 150 mm).
-
limetres).
6 38
+0.2
- 0.2
56
+0.2
- 0.2
Ø 3.2
Ø max. 82.5
120
35
50
98
Ø max. 150
Ø 25
NOTE:
For external rolls diameter higher to 100 mm it’s recommended to use a paper pre-tensioning device.
166
