4.5 Connections
KPM302 STD, KPM303 STD, KPM302 EJ, KPM303 EJ, KPM302 vSEL, KPM303 vSEL
KPM302 TF, KPM302 TF-EJ, KPM302 TF-vSEL, KPM302 TF-hSEL
RS232 24V
PC
USB device
PC
serial device
HUBPC
Power Supply cable
(included)
Power supply
ETHERNET UTP
standard cable
(pin-to-pin)
ETHERNET
CrossOver
standard cable
Serial
standard cable
USB
standard cable
ATTENTION: In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
NOTES:
When the RS232 and USB communication cables are connected to the printer at the same time, communication takes
place via the USB port.
For ease of reference, for some models is represented only the printer group without the triple feeder.
50
