5 OPERATION
5.1 Adjusting paper width
KPM302 STD, KPM303 STD, KPM302 EJ, KPM303 EJ, KPM302 vSEL, KPM303 vSEL, TK302 STD, TK303 STD
Paper width may be adjusted from
40 mm to 82.5 mm by pressing the
unlocking button and moving the
adjustable paper guide as shown in
To manage paper width from 20 mm
to 40 mm, apply the spacer on the
adjustable paper guide (see following
NOTE: For ease of reference, it is represented only the internal printer without external plastic chassis.
57
