6.2 Setup report
the description of device parameters see following paragraphs.
PRINTER NAME and
FIRMWARE MODULES
RELEASE
KEYS FUNCTIONS
PRINTER
STATUS
PRINTER
PARAMETERS
PRINTER SETTINGS
PRINTER TYPE ...................................<device model>
Barcode Reader ................................... Not Present
RFID module ........................................Not Present
PRINTING HEAD TYPE .......................<head model>
INTERFACE .........................................RS232
ETHERNET TYPE................................ 10/100Base-TX
PROGRAM MEMORY TEST................OK
DYNAMIC RAM TEST..........................OK
EEPROM TEST....................................OK
CUTTER TEST.....................................OK
PRINTER HEAD Rav ...........................561
HEAD VOLTAGE [V] = 24.55
HEAD TEMPERATURE [°C] = 26
POWER ON COUNTER = 3
PAPER PRINTED [cm] = 10
CUT COUNTER = 35
Printer Emulation............................ : CUSTOM/POS
RS232 Baud Rate .......................... : 115200 bps
RS232 Data Length........................ : 8 bits/chr
RS232 Parity .................................. : None
RS232 Handshaking ...................... : Xon/Xoff
Busy Condition ............................... : RxFull
USB Mass Storage......................... : Enabled
USB Address Number .................... : 0
Print Mode ...................................... : Normal
Autofeed ......................................... : CR disabled
Chars / inch .................................... : A=15 B=20cpi
Speed / Quality............................... : Normal
Paper Width.................................... : 82 mm
Paper Threshold ............................. : 60%
Notch/B.Mark Position.................... : Bottom
Notch/B.Mark Threshold................. : 40%
Notch Distance [mm] ...................... : +00.0
Notch/B.Mark Min. Width................ : 0 mm
Ticket Locking................................. : Disabled
PaperEnd Buffer Clear ................... : Disabled
Ticket Management ........................ : Disabled
Paper End Management ................ : Print All
RFID Module Baud Rate ................ : 38400 bps
Print Density................................... : 0%
[LF] enter Printer Setup
[FF] enter Ethernet Setup
[S1] enter Clock Setup
[S2] skip Setup
<device name>
SCODE: <code> - rel 1.00
BCODE: <code> - rel 1.00
FCODE: <code> - rel 1.00
UCODE: <code> - rel 1.00
DCODE: <code> - rel 1.00
CPLD - rel 1.00
