3.4 Device components: internal view
1. Paper out presence
2. Opening/closing front cover sensor
3. Cutter position sensor
4. Unlocking button for mobile paper guide
5. Mobile sensors for alignment notch
6. Head temperature sensor
7. Sensor of paper presence
8. Opening/closing upper cover sensor
6
2
4
5
3
1
1
7 7 5 8
NOTE: For ease of reference, for some models is represented only the standard model of internal printer group without
external plastic chassis or triple feeder.
