CVC 310 - Electrical Parts List

CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
15 - 3
15.3 Electrical Parts List
Item
Reference
Number
Part Number Description Specification Remark
1 TO-2-1 S1000921 Main Power Switch C3
2 KKM S1000792 Main Board C4
3 KKC S1000791 Interface Board C15
4 PWR5 S1000925 Power Board C18
5 DCMD-8 S1000789 DC Motor Drive *3
DC Motor Drive, Wrap
Belt
C8-W
DC Motor Drive,
Conveyor
C10
DC Motor Drive,
Separator
DC Motor Drive, Rotary
table
C11
C12-T
6
DRV5
DRV5
S1000790
S1000790
Stepper Motor Drive
Head A (Right)
Head B (Left)
C7
C7-1
7 UF80B11 S1000922 Fan C5
8
110V
220V
S1000788
S1000830
Transformer
(Toroidal type)
C16
9 PD-45A S1000924 DC Power Supply C17
10 10GEEG3E S1000923 EMI Filter C6
11 - - Power Box Case, Two
Fans
12 XBK300 S1000181 HHT Control Panel C1
13 KKXL24-1 S1000920 HHT Control Panel Cable C2
14 WL4G-3N1382P01
WL4G-2
WL9-2N
S1000407
Product sensor (SICK):
New type, standard
Old type, standard
Transparent container,
optional
SICK
15
Label-7
LRD6110
W0090067
LRD6110
Label Sensor
Standard type
Special type
CVC
LION
16 HPJ-D21 S1000145 Ribbon Sensor (optional) YAMATAKE
17 WL9-2N-431 S1000407 Backlog Sensor (optional) SICK
18
103H8222-5242
103H8223-5242
S1000032
S1000033
Labeling Stepper Motor:
Type A
Type B, C, D, E
SANYO
19
06SGN
3GN36K
3GN12.5K
S1000011
S1000076
S1000075
Separator:
Motor
Reducer (Separator
wheel)
Reducer (Separator
screw)
Bodine
20
08SGN
5GN36K
S1000012
S1000077
Infeed rotary table:
Motor
Reducer
TWT
21
33A5BEPM-W2 S1000013 Standard conveyor motor
Bodine (4183)
22
33A5BEPM-Z2 S1000014 Wrap Motor Bodine
23 - S3000194 Control Panel Membrane
