CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
10.2 Labeler Operation
a.. Turn on the main power switch and blower power switch.
b. The first identification screen is displayed as below:
10 - 2
After 3 seconds, the display is changed to:
c. Press F1 for auto adjustment. Both F2 and F3 are not functional for new products.
1) Press F1 key, place the label sensing point (red light) of the label sensor onto base (backing) paper.
* Remove the label before the label sensor (No label on the label sensor, refer to Fig 10.2-1).
2) Next two LCD displays show auto label sensing:
CVC
CVC 310
VER X.X
-JOB SELECTION-
F1 AUTO ADJ
F2 CALL MEMORY
F3
CURRENT MEM
Fig.10.2-1
LAB SENSING
F2 SENSITVY
F3 LAB SENS
AUTO ADJ
To Next Page
