CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
3) Label sensitivity is set after the above two readouts display. After that, the display will change to:
PLACE PRODUCT
ON CONVEYOR
FOR TEST
4) Place one product on the conveyor to the left of the product sensor when conveyor starts moving
slowly.
5) After the product passes through, the conveyor speed will increase, and two labels will be rapidly
dispensed (remove these labels) and the display will show:
READY TO START
6) After a few seconds, the display will change to the following. It shows the machine is ready to begin
labeling job.
MEMORY: 00
F1 OUTPUT:
F2 REMING:
F3 PD SPD:
7) Set F2 value (quantity of label roll) if necessary. It will show the label remaining quantity. A buzzer
separately sounds to alert the operator when the label remaining quantity falls to "500" and "200".
8) The machine stops automatically when label remaining quantity falls to "0". Normally F2 is set at
"0" if label remaining quantity is not necessary for operation.
9) SeflSet
TM
will decide the normal running speed. Operator is also able to change the speed if
necessary. For labeling speed adjustments, please refer to charter 11.
10) If the product is a clear bottle, to enter the bottle diameter is necessary:
Use key to search for the display which is shown as follows:
F1 PD LEN
F2 LA LEN
10 - 3
