CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
4.4 Transportation Procedures
a. Transport the machine to the installation site with its wooden crate or wooden base safely using a
2-ton minimum fork lift.
b. If the wooden base has already been removed, two people are required to hold each side of the
machine to maintain balance while moving.
c. Do not use a crane to transport the machine. No lifting attachments are provided on this machine.
d. After the fixing wood bars and webbings are removed, place the machine accurately in its place
with the fork lift as indicated in the figure (Fig 4.4-2).
Note: Keep the center of gravity aligned during movement, do not tilt the machine when moving. Fork
lift should be operated by qualified personnel.
Fig
4.4-1
Fig
4.4-2
4 - 4
