CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
4. INSTALLTION
4.1 Standard Area Conditions
a. Place the machine on a flat surface. Room temperature should range between 50°F ~ 104°F
(10°C~40°C). It is recommended that the temperature of the area be at around 70 °F (25°C). Keep
area free of vibration, and free of gaseous chemicals.
b. Relative humidity: 10% to 90% (no condensation).
c. Avoid direct sunlight over the machine, also avoid water splatters.
d. Have a clearance space of at least 800 mm (31½”) around the machine for operation, cleaning and
maintenance purposes (refer to Fig. 4.2-1).
4.2 Minimum Machine Operation Space
Model A B Height
CVC 310 (STD) 2,650 mm (104") 3,600 mm (142") 2,800 mm (110 ")
Fig
4.2-1A
4 - 1
