CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
11.2 Label Head Height Adjustment
Adjust the label head height with the head handwheel under the labeling head. Rotate the handwheel to
raise or lower the labeling head.
Fig 11.2-1
Label roll dis
k
Label head height
adj. handwheel
11 - 2
