CVC TECHNOLOGIES, INC. CVC 310 OPERATION MANUAL
5.4 C60 Type Arrangement of the Type Holder (Optional)
a. Whenever possible, it is suggested that the letter type are arranged in a centered and balanced way
within the type holder area for better results. (Depend on the actual situation of the label imprinting.)
Recommended
Less Recommended
Fig
5.4-1
Note: This is not always possible for all imprinting position requirements. In all cases, after
changing a new type holder or after installing new letter types, a fine adjustment is always
necessary.
b. The first letter close to the border should be always non-printing letter type (space or black tension
stopper), as it is not covered by the ink ribbon.
5 - 3
Fig
5.4-2
