Digital Sensor
Product Sensor <3P> Positioning Sensor <3P> (optional)
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 BRN
J31-1 DC 12V
1 BRN
J31-1 DC 12V, Positioning solenoid
2 BLU
J31-4 DC 12VG
2 BLU
J31-4 DC 12VG, Positioning solenoid
3
BLK J31-11
Signal cable
3 BLK
J31-12 Signal cable
Label Sensor & Hot Stamp Printer
Label Sensor <7P> Hot Stamper Printer <8P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 RED
J32-6
DLAV2, Sending signal input
Label sensor
1 ORG
J31-2
DC 12V Sensor power
(No ribbon or no print sensor)
2 WHT
J32-2
DC 12VG, Sending power,
Label sensor
2 GRN J33-7
DC 24VG
3 BLK
J32-7
VLSI2, Receiving signal output
Label sensor
3 RED
J33-15
Printing signal output
4 GRN
J32-3
DC 5V Receiving power
Label sensor
4 PPL J32-10
Detecting input
(No ribbon or no print sensor)
5 ORG
J31-2
DC 12V, Power
Clear label sensor
5 GRY J31-3
DC 12VG Sensor power
(No ribbon or no print sensor)
6 GRY
J31-3
DC 12VG, Power
Clear label sensor
6 WHT J30-2
AC OUT+ 110V
Power, printer
7 PPL
J31-10
Signal output
Clear label sensor
7 BLK
J30-3
AC OUT- 110V
Power, printer
8 YEL
J33-6 DC 24V
Backlog Sensor & Solenoid Valve
Backlog Sensor <4P> Positioning Solenoid Valve<4P>
Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition Pin No. Color Jump No. Definition
1 BRN
J31-1 DC 12V
1 YEL
J33-6 DC 24V
2 BLU
J31-4 DC 12VG’
2 PPL
J33-13
Solenoid
signal
3 YEL
J32-12 Sensor out
3
4 4
