CYBELEC DNC 60 PS User Manual

CREATING A PRODUCT PAGE 15
3rd sequence The following screen is displayed:
P 0 P+__ N 3 / 3 CY __
Th: 2.00 37.00 Kg/mm²
p/d 1/ 1 CR __/ri __.__
--MEM-- --POS-- --COR--
90.0° mes____.__
Y1 229.90 350.92 ____.__
Y2 229.90 351.05 ____.__
X 1 18.00 51.85 ____.__
Q ____ ____
Lmat 1000 TON 19
Rx ___ Ext start _
Vy _ _ ΔT _._s
TDC ___ SP ___
F1:___ F2:___ F3:___ F4:__ F5:__ Cr: 41
 Modify the values which are different for this sequence, in this case
enter the value 48 in the X field.
The programming of the product is terminated.
If you wish to save:
 Place the cursor on the P field.
(
and to position the cursor on the top of the page.)
 Introduce the number you wish to give to this product.
 Press
(if the system replies EXISTS, choose another number
for saving this product).
The product will be saved in the internal memory with the number
which you have given it.
It will, however, remain present in the work memory.
 Go to semi-automatic mode
.
 Call the sequence 1.
 Execute the first bend.
