PAGE 68 USER GUIDE DNC 60 PS
IDEAL CURVE
The ideal curve allows to make a bend with a large internal radius.
An ideal curve can be programmed on one or the other of these pages.
An ideal curve is defined by programming from 4 to 98 (programming 0, 2
or 3 will give an error).
Remark: For the result to be coherent, the number of bends to realize the
angle must be such that the length of each segment is greater
than half the length of the V opening of the die.
If this is not the case a message informs the operator and the re-
sult will be an angle too open.
In ideal curve mode, the software calculates different bend for the first, sec-
ond, next but last and last bend according to the drawing which follows.
