PAGE 66 USER GUIDE DNC 60 PS
PROGRAMMING THE AXES DATUM
Select option 11 of the main menu, the following page appears:
AXES DATUM
--SET-- --POS--
X _____.__ 0.00
Y1 ____.__ ____.__
Y2 ____.__ ____.__
Introduce in the SET column the values for the axes datum.
Leave the field for validation.
At this moment , the POS field takes the new value.
Dangerous operation
This operation can only be executed by an experimented operator who
knows the consequences of his modification.
If you modify the position of an axis in this way, make sure that it
corresponds to the reality. After modifying, the electronic, electrical
and mechanical limit switches are to verify. Generally the axis in
question is displaced in manual mode slow speed up to the nega-
tive/positive limit switch.
It is recommended not to modify Y1 and Y2.
If this should be the case however, a particular caution has to be
taken. In fact, if you modify here the position and an error is commit-
ted, the damages caused by this modification can be dangerous and/or
harmful for the functioning of the machine.
Furthermore this modification get lost at each restarting of the ma-
chine.
CALIBRATION
The CAL (calibration) field on the PRODUCT STATUS page is used for
the automatic compensation of variations in sheet metal thickness.
